| Power Supply |
DC 24V to 45V (Stand 36V) |
| Processor / CPU |
32-bit CPU Main Frequency >72M |
| Rectification Algorithm |
No overshot integral Variable PI Algorithm |
| Analogue Input |
3 Channel 0-6 V, impedance 20K |
| Sensor Voltage |
DC 12V, 350mA max |
| Response Time |
0.5 ms |
| Analogue Input Resolution |
12-bit ADC |
| Switch Contacts Input |
3 Channel – NPN |
| Web Control Mode |
EPC, LPC, CPC, SPC |
| Support Of Sensor Type |
Ultrasonic Sensor, Photoelectric Sensor, CCD Sensor |
| Actuator Speed |
14 mm to 40 mm per second (Adjustable) |
| Actuator Thrust |
100 kgf / 200 kgf / 400 kgf / 800 kgf |
| ESD Protection |
IEC 1000-4-2, +/- 15KV (Air), +/- 8KV (Contact) |
| Screen Display |
2.8’’ / 260 Colours TFT |
| Motor Drive |
Brushless DC Servo Motor |
| Protection Class |
IP-53 |
